Electrodynamics shaker
Impact Hammer
Typical accelerometer
Educational truss structure (PASCO Engineering)
Educational three-hinge frame (designed and fabricated at UVM)
Experimental three-dimensional braced-frame structure
Experimental three-dimensional braced-frame structure
40-channel data acquisition system (SCADAS)
channel data acquisition system (SCADAS)
reaction frame for vibration testing
reaction frame for vibration testing

The structural monitoring diagnosis and prognosis Lab is currently located in room 108 in Votey Hall at the University of Vermont. It contains the following equipment:

LMS Scadas 40 channel data adquisition system
LMS Scadas 8 channel data adquisition system
12 unidirectional accelerometers
8 dynamic strain sensors
1 impact hammer
1 120 lb pound electrodynamic shaker

Lab Equipment
